AI Powered RFID Reader

Name: "AI Powered RFID Reader"
Rating: 5 (321 reviews)

SKU: 1308747268

Model: 7355430955

Product Details

Product Specification

Type	AI Powered RFID Reader	Model	DL921 AI Enhanced UHF Long Range Reader with GPS/GSM/POE
Params	Type: DL921 AI Enhanced UHF Long Range Reader Fully Loaded GPS/GSM/POE Configuration Support protocol: ISO18000-6C, EPC Class 1 Gen 2, ISO18000-6B Operating Frequency: ISM 860MHz~868MHz, 902MHz~928MHz, or 920MHz~925MHz, frequency customization optional Working mode: Active Mode / Answer Mode / Trigger Mode / Password Mode Transmit power (Max): 26dBm Antenna: Built-in Circular Polarized antenna Reading Range: 0.1m~15m up to 82 feet maximum Anti-collision: Reads up to 50 pieces of tags simultaneously Read speed: The average read time for a single card is less than 10ms per 64 bits RSSI: Supported Received signal strength indication Read prompt: Buzzer SDK: Free SDK provided attached to the Reader Power supply: Power over Ethernet PoE / DC +9V~24V alternative Power consumption: 12W Operating Temp.: -20°C ~ +60°C Storage Temp: -40°C ~ +85°C Dimension: 450mm × 450mm × 70mm Weight: 4500g Case Color: Grayish White International Protection: IP65 Humidity: 5% to 95% non-condensing RS232 Port: Supported RJ45 Port: Supported with built-in Power over Ethernet PoE capabilities GPIO: Supported via integrated Trigger Port and Relay Port interfaces USB: Customizable configuration option 4g/wifi/bt: Integrated 2G/4G GSM cellular module WiFi customizable SDK Support: Comprehensive multi-platform development environment supporting X86 & X64, C++, C#, VB, Delphi, Linux, ARM, Python, NodeJS, QT, JAVA, and Android OEM & ODM Support: Full customized terminal layout and communication module matching available Advantage 1: All-in-one integrated design supports PoE single-cable power supply and network transmission, paired with built-in 4G GSM remote data transmission and GPS positioning functions. It realizes independent edge data collection, geographic trajectory recording and wireless upload, adapting to outdoor scenarios without fixed network infrastructure. Advantage 2: Adopts high-performance circular polarized antenna with ultra-long 15-meter reading distance, supporting angle-free identification of moving tags. Equipped with excellent multi-tag anti-collision capability, it can stably identify up to 50 tags at high speed, ensuring efficient and uninterrupted batch identification of fast-moving vehicles and assets. Advantage 3: Features IP65 industrial dustproof and waterproof grade and wide temperature resistance for all-weather outdoor stable operation. It integrates native relay and trigger IO ports to directly link gates and alarm devices for automatic on-site control, and supports full-platform secondary development and personalized hardware customization for diverse industrial solutions.	Material	Aluminum, Durable ABS, rfid chip, PCB board
Applicable Industry	All-weather intelligent transportation and highway toll vehicle remote identification and automatic trajectory recording; container trucks and engineering vehicle fleet real-time inventory scanning and GPS position tracking; port terminals, railway yards and large logistics open-area asset unattended monitoring; industrial parks, military bases and quarry perimeter access control and automatic gate barrier linkage management
