RFID Reader

Type: POS & Autonomous Retail Model: Self-Checkout RFID Reader Params: Type: Self-Checkout RFID Reader Support protocol: ISO18000-6C, EPC Class 1 Gen 2 Operating Frequency: ISM 860MHz~868MHz, 902MHz~928MHz, or 920MHz~925MHz, frequency customizable from 860MHz~960MHz Working mode: Active Mode & Answer Mode Transmit power (Max): 33dBm Antenna: Integrated low-profile flat-panel near-field RFID reader antenna Reading Range: 0.1m~5m, software adjustable and optimized for close-proximity countertop scanning Anti-collision: Reads up to 80–100 pieces of tags simultaneously Read speed: The average read time for a single card is less than 10ms per 64 bits RSSI: Supported Received Signal Strength Indication for precise item proximity validation Read prompt: Buzzer SDK: Free SDK provided attached to the Reader Power supply: DC +12V ~ 24V Power consumption: 12W Operating Temp.: -20°C ~ 60°C Storage Temp: -40°C ~ 85°C Dimension: 400mm × 300mm × 35mm Weight: 1500g Case Color: Gray and White, customizable International Protection: IP66, effectively resistant to commercial counter liquid spills and dust Humidity: 5% to 95% non-condensing RS232 Port: Supported RJ45 Port: Supported standard TCP/IP connectivity for network terminals GPIO: Supported for linkage with smart checkout lane gates and indicator lights USB: Supported for direct connection with retail POS computers 4g/wifi/bt: Optional hardware expansion available SDK Support: Broad multi-platform ecosystem supporting Windows X86/X64, C++, C#, VB, Delphi, Linux, ARM, Python, NodeJS, QT, JAVA, and Android OEM & ODM Support: Customizable dimensions, shapes, colors and flush-mount shell plates for self-checkout kiosk integration Advantage 1: Equipped with high-performance anti-collision algorithm supporting simultaneous reading of up to 100 tags, enabling one-second batch identification of full-basket goods. It replaces traditional single barcode scanning, greatly improving self-checkout efficiency and reducing queuing bottlenecks in retail scenarios. Advantage 2: Features IP66 industrial dustproof and waterproof grade with excellent commercial scene adaptability, effectively resisting counter liquid splashes, dust and daily cleaning erosion. Adopts ultra-slim flat-panel design for seamless embedding in cash counters and self-service kiosks with neat appearance and strong integration compatibility. Advantage 3: Supports RSSI precise proximity filtering and near-field beam control, accurately identifying only items within the checkout zone and avoiding cross-interference from adjacent customer goods. It is equipped with complete industrial interfaces and full-platform SDK development support, realizing fast docking and stable linkage with various POS systems and self-checkout equipment. Applicable Industries: Unmanned convenience store self-service checkout and background transaction data recording; apparel and fashion retail high-efficiency counter batch tag identification and quick settlement; library self-service book and document automatic borrowing and renewal processing; hospital pharmacy prescription drug pouch and medical specimen accurate verification and handover management Material: ABS/PC engineering plastic, rfid chip,PCB board Applicable Industry: Apparel and retail garment tag encoding, quality testing and product ID serialization management before shelf placement; medical and pharmaceutical industry miniature reagent and specimen RFID tag precise initialization and encryption writing; RFID inlay and label manufacturing batch quality inspection and defective product automatic screening; enterprise access control badge and large-scale event ticket intelligent encoding and credential locking management Self-Checkout RFID Reader POS
